Part Number:
981.321
Actual Diameter:
5 - 7/8"
Thread size:
M8 bolt
Backing Material:
HOOK
This backing plate was made specifically for use with the Rupes® 6" LHR21ES BigFoot Random Orbital Polisher. Also fits the LHR15ES, allowing the machine to be outfitted with 6" (150mm) pads and discs. If you have used this plate and believe that the Velcro holds onto your pads too strongly, then give the 981.320 backing plate a shot (gray scrub plate).
Price:
$42.06
Qty:
Rupes 6" Velcro Backing Plate - fits LHR 21ES

Rupes 6" Velcro Backing Plate - fits LHR 21ES

Rupes 6" Velcro Backing Plate - fits LHR 21ES
Click to enlarge image(s)
BigFoot's dance moves can be tough on shoes.

The Rupes LHR 21ES is quite a tool.  It delivers a 21mm ø orbit, and tops out at 4,200 RPM.  Knowing this, it's no big surprise that eventually you'll need to replace its backing plate.  Over time, the backing plate's attachment hooks can degrade or break away, causing pads and discs to fling from the machine during use!

Surprisingly, the primary reason backing plates need to be changed is not due to wear.  The fact is, nothing can relegate a backing plate to the trash bin faster than an accidental dropping of the machine.

Regardless of how it happens, if the machine takes a fall and crashes to the ground, there's a very high likelihood that the mounting pad (essentially a stamped steel washer) will bend.  If this happens, you'll be dead in the water unless you've got a backup plate on hand.

This backing plate is the genuine article!  A direct replacement Rupes® 981.321 150mm Backing Plate, made specifically for use with the Rupes® LHR 21ES BigFoot Random Orbital Polisher.  Also fits the LHR 15ES, allowing the machine to be outfitted with 6" (150mm) pads and discs.

Looking for a 5" version of this backing plate?  We've got it here!
Specifications
  • Actual diameter: 5-7/8" (148mm)

  • Attachment material:
    Velcro®- low profile hook
  • Weight: 126g approximate (4.45 oz.)

  • Extra hold hook material:
    Carefully remove polishing pads to avoid damaging the loop material

Part Number:
106GG
Actual Diameter:
5 - 13/16"
Thread size:
5/16-24
Backing Material:
MICRO HOOK
This is one of our most popular backing plates.  It features a traditional flare-shaped edge, allowing for progressive flexibility over contours and curves.  The micro hook attachment material is very durable and grippy.  This plate is well built, balanced, and will last a long time.
Price:
$24.80
Qty:
Mirka 6" Diameter Backing Plate - Hook Face

Mirka 6" Diameter Backing Plate - Hook Face

Mirka 6" Diameter Backing Plate - Hook Face
Hook & Loop
Click to enlarge image(s)
Hook face, compatible with all hook & loop systems.

One of our best sellers, and for good reason! For starters, this plate features more flexibility than its vinyl backed counterpart (Mirka #106).

The medium density polyurethane foam used as the core of this plate is firm enough to level substrates, but thanks to its flared edge, conformability is good when used on curved surfaces.

Mirka's backing plates are manufactured using a top quality molded polymer construction. This means that the black hub, yellow foam center, and white face are molded together, not glued.

Each plate is balanced to eliminate vibration, so you can work comfortably.

To view our entire backing plate lineup, visit the Backing Plate Main Page.

Specifications
  • Actual diameter: 5-13/16"

  • Attachment material: hook

  • Max speed: 13,000 r.p.m.
  • Thread size: 5/16"-24 male

  • Height to mounting pad: 7/16"

  • Weight: 130g (4.6 oz.)

Part Number:
106SG
Actual Diameter:
5 - 5/8"
Thread size:
5/16-24
Backing Material:
MICRO HOOK
This plate features a soft urethane core that is 9/16" tall, so it's a perfect choice when contouring ability is a must. This is not a flimsy plate, and should last a long time. It feels nice, and works equally well with sanding discs and buffing pads.
Price:
$29.52
Qty:
Mirka 6" Diameter Backing Plate - Hook Face

Mirka 6" Diameter Backing Plate - Hook Face

Mirka 6" Diameter Backing Plate - Hook Face
Hook & Loop
Click to enlarge image(s)
Compatible with all hook & loop systems.

This plate features a soft urethane core that is 9/16" tall, so it's a perfect choice when contouring ability is a must. This is not a flimsy plate, and should last a long time. It feels nice, and works equally well with sanding discs and buffing pads.

At 146 grams (5-1/8 oz.), this plate is heavy compared to plates featuring a similar diameter. The weight can be a plus if you are replacing a larger diameter plate in hopes of using smaller diameter discs or pads (such as when using the currently popular Dynabrade Dual Action Buffing Head).

Mirka's backing plates are manufactured using a top quality components.

Each plate is balanced to eliminate vibration, so you can work comfortably.

To view our entire backing plate lineup, visit the Backing Plate Main Page.

Specifications
  • Actual diameter: 5-5/8"

  • Attachment material: micro-hook

  • Max speed: 13,000 r.p.m.
  • Thread size: 5/16"-24 male

  • Height to mounting pad: 7/16"

  • Weight: 146g (5-1/8 oz.)

Part Number:
916SGV
Actual Diameter:
5 - 13/16"
Thread size:
5/16-24
Backing Material:
MICRO HOOK
This backing plate's hook has been optimized for use with Mirka's net mesh sanding discs. Still, it'll work with most hook & loop systems.  It is very soft and flexible compared to other Mirka plates.  When paired with a vacuum system, 52 holes allow thorough cleaning of the surface.
Price:
$37.30
Qty:
Mirka 6" Diameter Soft-Edge Backing Plate - Abranet/Autonet

Mirka 6" Diameter Soft-Edge Backing Plate - Abranet/Autonet

Mirka 6" Diameter Soft-Edge Backing Plate - Abranet/Autonet
Compatible with most hook & loop systems.
Click to enlarge image(s)
Designed for Abranet® & Autonet™ discs.

This particular backing plate is designed for use with Abranet® and Autonet™ discs. It features 52 vacuum holes and is designated as "soft", so it contours to complex or curved shapes quite well.

The face of the plate features a hook material that has been specifically designed for Abranet® and Autonet™ discs, but it works well with virtually any loop-style sanding disc.

Mirka's backing plates are manufactured using a top quality molded polymer construction. This means that the hub, foam center, and face are molded together, not glued.

Each plate is balanced to eliminate vibration, so you can work comfortably.

To view our entire backing plate lineup, visit the Backing Plate Main Page.

Specifications
  • Actual diameter: 5-13/16"

  • Attachment material: hook

  • Max speed: 13,000 r.p.m.

  • "Soft" designation means backing plate easily contours to complex surfaces
  • Thread size: 5/16"-24 male

  • Height to mounting pad: 15/32"

  • Weight: 130g (4.6 oz.)

  • Designed for use with Abranet® and Autonet™ sanding discs

Part Number:
W68DA
Actual Diameter:
5 - 15/16"
Thread size:
5/16 - 24
Backing Material:
MICRO HOOK
This backing plate is a perfect mate for Meguiar's® Soft Buff 2.0 Pads. Works great with the all-new Meguiar's 6" Microfiber Discs, too. Lots of bells and whistles are designed into this beauty. A precisely-sized flexible outer edge helps to minimize pad hazing, while the ultra durable micro hook attachment material keeps the pad locked into place. A big surprise- buffing pads are easy to remove!
Price:
$29.00
Qty:
Meguiar's Professional 6" D/A Polisher Backing Plate

Meguiar's Professional 6" D/A Polisher Backing Plate

Meguiar's Professional 6" D/A Polisher Backing Plate
Click to enlarge image(s)
A perfect mate for Meguiar's® Soft Buff 2.0 Pads.

Leave it to Meguiar's to design a backing plate that perfectly fits their buffing pads. This unique system approach allows Meguiar's to squeeze every bit of capability from their hardware.

This backing plate will increase buffing pad performance and durability, optimizing polishing performance in the process. What's the big deal, you ask? A lot!

For starters, the outer edge of the plate has been designed to help minimize pad hazing. Plate thickness is varied, which allows the buffing pad to better contour to complex surfaces.

The specialized low profile Velcro® attachment material secures the pad to the plate, gently yet powerfully locking it in place until the job is done.  Sweating the small details pays off, as a light pull of the pad easily releases it. The attachment material has been purposely eliminated along the outer edge of the face. This seemingly small detail increases flexibility of the pad, but more importantly eliminates "edge-digging", which often occurs when the hook material "cuts" into the back of the buffing pad.

Finally, the center of the face has been cut from the plate, eliminating edge digging at the center of the pad, dropping temperature buildup in the process. It's an extra step that is seemingly insignificant, but longevity of the buffing pad is increased.  Thanks Meguiar's!

"Failure is not an option!"
Durability is superb, thanks to its one-piece molded design.

To view our entire backing plate lineup, visit the Backing Plate Main Page.

Specifications
  • Actual diameter: 5-15/16"

  • Attachment material:
    Velcro®- low profile hook

  • Velcro® diameter: 4-7/8"
  • Thread size: 5/16"-24 male

  • Height to mounting pad: 7/16"

  • Weight: 111g (3.92 oz.)

  • Long lasting:
    One piece molded construction

Part Number:
106
Actual Diameter:
5 - 13/16"
Thread size:
5/16-24
Backing Material:
VINYL
This plate features a somewhat blunt edge, so it can take quite a bit of abuse. Even so, it still offers good flexibility. The vinyl backing material is very durable, so it can withstand a lot of disc changing. As is the case with all Mirka backing plates, this one is durable and balanced. Plan on having this sturdy work horse a long time.
Price:
$22.20
Qty:
Mirka 6" Diameter Backing Plate- Vinyl Face

Mirka 6" Diameter Backing Plate- Vinyl Face

Mirka 6" Diameter Backing Plate- Vinyl Face
Vinyl Face / PSA
Click to enlarge image(s)
Vinyl Face. for use with PSA discs.

The medium density polyurethane foam used as the core of this plate is firm enough to level substrates, but will give a small degree.

It does not have a sharply flared edge, so it has less give than its hook-backed counterpart (Mirka #106GG). The added edge height means this plate can take quite a beating.

Its vinyl backing material is very durable, so it can handle a lot of disc changing.

Mirka's backing plates are manufactured using a top quality molded polymer construction. This means that the black hub, yellow foam center, and white face are molded together, not glued.

Each plate is balanced to eliminate vibration, so you can work comfortably.

To view our entire backing plate lineup, visit the Backing Plate Main Page.

Specifications
  • Actual diameter: 5-13/16"

  • Attachment material:Vinyl
  • Thread size: 5/16"-24 male

  • Height to mounting pad:7/16"

  • Weight:130g (4.6 oz.)

Part Number:
WRSBP
Actual Diameter:
5 - 3/4"
Thread size:
5/8 - 11
Backing Material:
HOOK
6" Soft Buff Rotary SOFT Backing Plate
Designed to minimize the potential for pad-induced swirl marks, it is remarkably comfortable to use. Cushiony material allows the buffing pad to conform easily to flat or curved surfaces, thus minimizing the potential for grabiness of the pad, pad hop, and pad chatter.
Price:
$35.49
Qty:
Meguiar's Soft Buff 6" Rotary SOFT Backing Plate

Meguiar's Soft Buff 6" Rotary SOFT Backing Plate

Meguiar's Soft Buff 6" Rotary SOFT Backing Plate
Click to enlarge image(s)
"Eww, it's GUSHY..!"

My new favorite rotary plate!  The WRSBP Soft Buff 6" Rotary SOFT Backing Plate offers up plenty of support for 6", 7", and 8" diameter buffing pads. Designed to minimize the potential for pad-induced swirl marks, it is remarkably comfortable to use. Cushiony material allows the buffing pad to conform easily to flat or curved surfaces, thus minimizing the potential for grabiness of the pad, pad hop, and pad chatter.

The WRSBP's molded design is virtually indestructible, while its micro-hook face attaches strongly to pretty much all Velcro-style buffing pads (yet pad removal remains a breeze).

Pair with Meguiar's Rotary Foam Pads, or Meguiar's super low profile DA Foam Discs.

Increased comfort, superior results, and quality throughout.


To view our entire backing plate lineup, visit the Backing Plate page.

Specifications
  • Actual diameter: 5-3/4"

  • Attachment material: hook
  • Thread size: 5/8-11 female

  • Weight: 80g (2.82 oz.)

Part Number:
W65
Actual Diameter:
6 - 3/8"
Thread size:
5/8 - 11
Backing Material:
HOOK
A lot of engineering went into this design. Similar to its little brother (W64), this plate features one-piece molded construction for durability. Its edge is purposely soft in order to minimize paint swirling. The face of the pad features a self-centering (removable) plug that ensures perfect pad alignment, when used with appropriate pads.
Price:
$23.74
Qty:
Meguiar's Professional 6-3/8" Rotary Backing Plate

Meguiar's Professional 6-3/8" Rotary Backing Plate

Meguiar's Professional 6-3/8" Rotary Backing Plate
Click to enlarge image(s)
It looks stealth, but you'll surely notice the quality.

Meguiar's has made this model of backing plate for many years, but this is an all-new design. Durability is top notch, thanks to its sturdy one-piece molded construction.

As before, it features a pad alignment plug (located at the center of the face), making it a snap to align buffing pads that utilize a centering hole.

The face of the plate is firm with a minute amount of cushioning, virtually guaranteeing a smooth feel while polishing.

The outer edge has been finessed to allow increased contourability of the pad when used on complex surfaces, or for those times when the pad must be tilted on edge for targeted buffing.



To view our entire backing plate lineup, visit the Backing Plate page.

Specifications
  • Actual diameter: 6-3/8"

  • Attachment material: hook

  • Patented design:
    Centering plug ensures perfect pad alignment
  • Thread size: 5/8-11 female

  • Weight: 144g (5.08 oz.)

  • Long lasting:
    One piece molded construction

Part Number:
W66
Actual Diameter:
5 - 3/4"
Thread size:
5/8 - 11
Backing Material:
HOOK
Known as the "EASY-BUFF", this backing plate was originally introduced as an integral part of the Meguiar's So1o™ One Liquid System. Since then, it has garnered quite a following. Its foam center distributes pressure evenly, enabling buffing pads to easily contour to complex shapes. Increased comfort & better results... GREAT!
Price:
$29.46
Qty:
Meguiar's So1o™ 6" Easy-Buff Rotary Backing Plate

Meguiar's So1o™ 6" Easy-Buff Rotary Backing Plate

Meguiar's So1o™ 6" Easy-Buff Rotary Backing Plate
Click to enlarge image(s)
"It's funky and utterly unique. You MUST own one."

 10-29-2015 NOTE:  This product has been replaced by the WRSBP.

This backing plate was originally introduced as an integral part of the Meguiar's So1o™ One Liquid System, but it performs incredibly well when paired with the majority of foam or wool buffing pads available today.

While it can be difficult to find the proper balance between flexibility and firmness, this plate hits the mark.  Credit must go to the carefully shaped, engineered foam center.

In addition, the specialized foam has been optimized to minimize the potential for pad-induced swirl marks.

Increased comfort, superior results, and quality throughout.

 10-29-2015 NOTE:  This product has been replaced by the WRSBP.

Note:
For maximum performance, pair with any of the So1o™ wool or foam buffing pads.  With a quartet to choose from, you're certain to find the right combination!


To view our entire backing plate lineup, visit the Backing Plate page.

Specifications
  • Actual diameter: 5-3/4"

  • Attachment material: hook
  • Thread size: 5/8-11 female

  • Weight: 80g (2.82 oz.)

Part Number:
106HDGP
Actual Diameter:
5 - 7/8"
Thread size:
5/8 - 11
Backing Material:
LARGE HOOK
This firm-backed backing plate features a urethane molded center and large hooks for proper attachment to non-woven abrasive discs, such as Mirka Mirlon or Mirlon Total™. It can also be used for grinding with Mirka Abranet HD discs up to 6,000 RPM.
Price:
$21.84
Qty:
Mirka 6" Diameter Large-Hook Backing Plate - firm face

Mirka 6" Diameter Large-Hook Backing Plate - firm face

Mirka 6" Diameter Large-Hook Backing Plate - firm face
Click to enlarge image(s)
Large-hook attachment material is designed for use with Abranet® HD, Mirlon, and Mirlon Total™ discs.

Mirka's Abranet HD Discs are stout. They're so tough, they can be used as grinding discs!

To keep them from slinging off at high RPM, you'll want to use this plate. The large-hook attachment material is also ideal for use with non-woven discs, such as Mirka Mirlon, Mirlon Total™, and 3M Scotch-Brite™ discs.

This is a stiffly-backed plate, and is rated for speeds up to 6,000 RPM.

Need a backing plate with more flexibility?
Check out the Ferro GP-36.  It is soft-backed, and is safe for use up to 4,800 RPM.

To view our entire backing plate lineup, visit the Backing Plate Main Page.

Specifications
  • Actual diameter: 5-7/8"

  • Attachment material:
    large hook

  • Max speed: 6,000 r.p.m.

  • Alternate number:
    Ferro GP-916U or 6396
  • Thread size: 5/8-11 female

  • Weight: 000g (0.00 oz.)

  • Designed for use with:
    Non-woven discs such as Mirka Mirlon, Mirlon Total™, and 3M Scotch-Brite™ pads
